PowerCage 1600 Enclosure • Specifications and Part Numbers 21
Power consumption
System ..................................... Enclosure without boards: 12.4 watts
Individual FOX boards .............. FOX Tx VGA: 5.68 watts
FOX Rx VGA: 6.54 watts
FOX Tx DVI: 5.67 watts
FOX Rx DVI: 5.50 watts
FOX 3G HD-SDI: 1.84 watts
FOX Tx AV: 6.89 watts
FOX Rx AV: 5.57 watts
FOX DVI Plus Tx: 5.68 watts
FOX DVI Plus Rx: 6.18 watts
FOX Tx HDMI: 5.68 watts
FOX Rx HDMI: 6.18 watts
Individual MTP boards .............. MTP T 15HD RSA: 4.30 watts
MTP R 15HD RSA SEQ: 8.38 watts
MTP T AV: 2.69 watts
MTP R AV: 3.92 watts
Power input requirements for boards . 12 VDC, 1.0 A, supplied by the PowerCage enclosure
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Enclosure: fans, front to back
Boards: convection, within the PowerCage enclosure
Thermal dissipation ........................ 27.6 BTU/hr
Mounting — PowerCage enclosure
Rack mount ............................. Yes
Enclosure type ................................ Metal
Enclosure dimensions
PowerCage enclosure .............. 5.25" H x 17.0" W x 12.25" D (3U high, full rack wide)
13.3 cm H x 43.2 cm W x 31.2 cm D
(Depth excludes connectors on the optional boards. Width excludes rack ears.)
PowerCage FOX boards ........... Each fits a double slot opening in a PowerCage enclosure.
PowerCage MTP R 15HD RSA SEQ
Each fits a double slot opening in a PowerCage enclosure.
All other boards ....................... Each fits a single slot opening in a PowerCage enclosure.
Product weight
PowerCage enclosure .............. 11.6 lbs (5.3 kg)
PowerCage FOX boards ........... 1.1 lbs (0.5 kg)
PowerCage MTP R 15HD RSA SEQ
1.0 lbs (0.5 kg)
All other boards ....................... 0.8 lbs (0.4 kg)
Shipping weight
PowerCage enclosure .............. 13 lbs (6 kg)
Boards ..................................... 2 lbs (1 kg) each
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
Additionally for FOX boards: FDA Class 1
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTE: All nominal levels are at ±10%.
NOTE: Specifications are subject to change without notice.
8.0-022112-D9
