PowerCage 1600 Enclosure • Specifications and Part Numbers

Specifications and

Part Numbers

This section of the guide includes the following material:

Specifications

Part Numbers (for included parts and accessories)

Specifications

NOTE: The PowerCage FOX boards are available in singlemode or multimode versions.

NOTE: The optional PowerCage FOX boards are class 1 laser products. They meet the safety regulations of

IEC-60825, FDA 21 CFR 1040.10, and FDA 21 CFR 1040.11.

Optical specifications — PowerCage FOX boards, interconnection between

transmitter and receiver

Number/type .................................. 1 singlemode or 1 multimode fiber optic input and output per FOX board, up to

8 double space boards per PowerCage enclosure

NOTE: Only one fiber is required to transmit video, audio, and unidirectional data. A second fiber is required to

transmit return data for bidirectional control/communication.

Connectors .................................... 2 bidirectional LC connectors per FOX board
Operating distance

Singlemode ............................. 30 km (18.75 miles) with singlemode (SM) cables with a SM board
Multimode ............................... 300 m (985') with 62.5 µm OM1 multimode (MM) cable and a MM board

1 km (3280') with 50 µm OM2 multimode (MM) cable and a MM board
2 km (6561') with 50 µm OM3/OM4 2000 MHz bandwidth laser optimized MM
cable and a MM board

NOTE: Operating distance is approximate. These are typical distances. The maximum distance may be greater

than these typical numbers depending on factors such as fiber type, fiber bandwidth, connector splicing,
losses, modal or chromatic dispersion, environmental factors, and kinks.

Nominal peak wavelength .............. 850 nm for multimode (MM), 1310 nm for singlemode (SM)
Transmission power, singlemode or multimode

-5 dBm, typical

Maximum receiver sensitivity

Singlemode ............................. -18 dBm, typical
Multimode ............................... -12 dBm, typical

Optical loss budget

Singlemode ............................. 13 dB, maximum
Multimode ............................... 7 dB, maximum

Maximum channel data rate

PowerCage FOX AV boards ...... 2.125 Gbps
PowerCage FOX HDMI boards . 4.95 Gbps (1.65 Gbps per color)
Other PowerCage FOX boards . 4.25 Gbps
