PowerCage 1600 Enclosure • Installation
4
Installation
Topics covered in this section of the guide include the following:
z
Enclosure and Rear Panel Features
z
Installing the Transmitter and Receiver Board into the Enclosure
z
z
The boards and power supplies are hot-swappable and can be installed or replaced at any
time. However, the most convenient way to proceed with initial installation is as follows:
1.
Install the optional redundant power supply and transmitter and receiver boards in the
enclosure.
NOTES:
•
Cover all empty board slots; do not leave them open. Securely fasten the
screws for boards and blank panels.
•
Use a tool to fully tighten the screws after initial installation and
subsequent removal and replacement of the boards.
2.
Mount the enclosure to an equipment rack.
3.
Connect cables to the transmitter and receiver boards and to input and output devices.
4.
Connect the power cable to the unit and test the system.
Heed the following safety information when installing or servicing the PowerCage system:
CAUTION: The PowerCage uses double pole/neutral fusing.
Power must be disconnected before servicing internal components.
Do not leave empty board slots open or uncovered while the unit is
powered on.
