MTP U T A D • Introduction 2
Twisted Pair Cable
Twisted pair (TP) cable is much smaller, lighter, more flexible, and less expensive than coaxial
cable. These TP products make cable runs simpler and less cumbersome. Termination of the
cable with RJ-45 connectors is simple, quick, and economical.
Transmission Distance
NOTE: This transmitter provides pre-peaking, which boosts the signal before it is
transmitted.
The maximum distance is determined by the frequency and resolution of the signal that is
input to the transmitter. The table on the next page specifies the recommended maximum
transmission distances and transmitter Pre-Peak switch positions (refer to the applicable
transmitter guide) using Extron Enhanced Skew-Free A/V UTP cable or UTP CAT 5, 5e, or
6 cable, terminated with RJ-45 connectors.
NOTES: • It is possible to exceed the recommended distance; however, image quality
may be reduced.
• The MTP units are designed for and perform best with Extron Enhanced
Skew-Free A/V cable terminated in accordance with the TIA/EIA T 568 A wiring
standard. CAT 5, 5e, and 6 cables are acceptable, but less preferable. We also
recommend the use of preterminated and tested cables. Cables terminated on
site should be tested before use to ensure that they comply with Category 5
specifications.
