MTP U T A D • Reference Information 15
Audio
Number/signal type ........................ 1 set of proprietary analog signals
Connectors .................................... 1 female RJ-45
Gain ............................................... Unbalanced output: 0 dB;
balanced output: +6 dB
Frequency response ........................ 20 Hz to 20 kHz, ±1 dB
THD + Noise ................................... 0.15% @ 1 kHz, 0.3% @ 20 kHz at nominal level
S/N ................................................. >70 dB at maximum output (unweighted)
Stereo channel separation .............. >60 dB @ 1 kHz
CMRR ............................................ >43 dB @ 20 Hz to 20 kHz
Audio input
Number/signal type ........................ 2 stereo, unbalanced
Connectors .................................... (1) 3.5 mm mini stereo jack
1 pair female RCA
Impedance ..................................... >10k ohms, unbalanced
Nominal level ................................. +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +18 dBu, (unbalanced) at 1%THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
General
Recommended cable type .............. CAT 5/5E/6 (shielded or unshielded) or Extron Enhanced Skew-Free AV UTP
External power supply .................... 100 VAC to 240 VAC, 50-60 Hz, external;
to 12 VDC, 1 A, regulated
Power input requirements .............. 12 VDC, 0.5 A
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Convection, no vents
Mounting
Rack mount ............................. No
Furniture mount ...................... Wall or furniture mountable in a
Decora ® -style opening
Enclosure type ................................ Metal
Enclosure dimensions
Faceplates ................................ Two [2.6" H* x 1.3" W x 0.2" D
(6.6 cm H* x 3.3 cm W x 0.6 cm D)]
(Fits the openings in a 2 gang Decora faceplate.)
*Height is 4.1" (10.4 cm) including mounting tabs.
Device ..................................... Two [2.7" H x 3.2" W x 1.5" D
(6.9 cm H x 8.1 cm W x 3.8 cm D)]
(Depth excludes input connectors.)
Product weight ............................... 0.4 lbs (0.2 kg)
Shipping weight ............................. 2 lbs (1 kg)
Vibration ........................................ ISTA 1A in carton
(International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES: • All nominal levels are at ±10%.
• Specifications are subject to change without notice.
