MTP U T A D • Installation and Operation
10
Rear Panel Features
OUTPUT
1
_
4
+
12 V
.5A
MAX
3
2
11
12
13
Figure 6.
Transmitter Rear Panel Features
k
Output connector — Connect a TP cable from this RJ-45 female connector to the
compatible receiver (see “
” to wire the RJ-45 connectors).
NOTE: See the
on page 3 for recommended transmission ranges.
l
Contact closure controls — To select a video input to output, momentarily tie the
assigned pin for that format to ground.
Pin
Format
Pin
Format
Pin
Ground
1
Composite
3
YUV
5
Ground
2
S-video
4
PC
NOTE: The front panel Contact DIP switch (
h
) must be on (up) for contact closure
to be available.
m
DC power connector — Plug the external 12 VDC, 1 A power supply into this 2-pole
captive screw connector (see "
" to wire the connectors).
NOTE: The remote power capabilities available with certain MTP models are not
supported by this unit; the transmitter and receiver both must be powered.
