MTP U T A D • Installation and Operation
9
Configuration switches
The configuration switches (
h
and
i
) will be inaccessible once the Decora faceplate is
installed.
h
DIP switches
•
Contact (1) — Set this switch on (up) for contact closure control of the input
selection. Set this switch off (down) to put the transmitter in auto switch mode (the
transmitter automatically selects the highest format video input with a sync signal
present).
•
Pre-Peak (2) — Set this switch on (up) to alter the TP signal output to compensate
for long cable runs. Set this switch off (down) for an unpeaked TP output. See
the
on page 4 for suggested switch settings based on the transmitted video
format and transmission distance.
•
50 Hz Refresh (3) — Set this switch on (up) for 50 Hz refresh rate for the resolution
selected by the EDID Select switch. Set this switch off (down) for 60 Hz.
i
EDID Select rotary switch — Set this switch to one of the positions below to select
the local monitor as the source of the EDID data or a specific resolution.
•
Position 0 — The loop-through monitor (
, on page 6) is the source of the EDID
data.
•
Position 1 - F — Specify a resolution. The following table identifies the switch
positions and the associated resolutions. By default, the vertical refresh rate for
all resolutions is 60 Hz. The resolution can be set to 50 Hz using the Refresh DIP
switch (
Pos.
Source or
Resolution
Pos.
Resolution
Pos.
Resolution
0
Local monitor
6
1280 x 1024
C
1680 x 1050
1
800 x 600
7
1360 x 768
D
1920 x 1080
2
1024 x 768
8
1366 x 768
E
1920 x 1200
3
1280 x 720
9
1400 x 1050
F
Not used
4
1280 x 768
A
1440 x 900
5
1280 x 800
B
1600 x 1200
Status LEDs
j
LEDs —
•
Power — This LED indicates power is applied to the MTP.
•
Active input — The lit LED (PC, YUV, S-VID, or VID) indicates the video input that is
selected for output on the TP connector.
NOTE: When an input selection is made in contact closure mode, and no signal
is active on the input, the selected LED blinks.
