MTP U T A D • Reference Information
14
Reference
Information
The section provides information on:
•
•
•
Specifications
Video
Gain ............................................... Unity
Number/signal type ........................ 1 set of proprietary analog signals
Connectors .................................... 1 female RJ-45
Video input and loop through
Number/signal type ........................ 1 analog RGBHV, RGBS, RGsB, RsGsBs, component video, S-video, or composite video input
1 component video (YUV bi-level or tri-level sync)
1 S-video
1 composite video
1 buffered RGBHV, RGBS, RGsB, RsGsBs, component video, S-video, or composite video
loop through
Connectors .................................... 1 female 15-pin HD (RGB, RGBS, RGsB, RsGsBs)
3 RCA (component video)
1 female 4-pin mini DIN (S-video)
1 RCA (composite video)
1 female 15-pin HD (RGB buffered loop through)
Nominal level ................................. 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.45 Vp-p
Impedance ..................................... 75 ohms
Horizontal frequency ...................... 15 kHz to 130 kHz
Vertical frequency ........................... 30 Hz to 150 Hz
Return loss ..................................... <-30 dB @ 5 MHz
DC offset (max. allowable) ............. 250 mV
Sync
Input type ...................................... RGBHV, RGBS, RGsB, RsGsBs
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level ...................................... 3.5 V to 5.5 Vp-p, unterminated
Input impedance ............................ 573 ohms ±5%
Max. input voltage ......................... 5.5 V p-p
Polarity ........................................... Positive or negative (follows input polarity)
