6
MSX1616 OPERATION MANUAL - v1.0 5/8/02
2002 - INLINE, INC.
•
Dual Switching Modes
o
Matrix mode – Lets you configure new or change existing input-output patches
with the press of one button.
o
Express mode – Lets you recall previously stored input/output patches.
•
RGB Delay mode for enhanced switching translations.
•
256 Configuration Memories let you to store and recall input/output configurations,
audio levels, and auxiliary serial commands.
•
Blank Front Panel Versions are available at a lower cost.
MSX1616 model Numbers
16 x 16 Matrix Switcher 160 MHz
With Faceplate
Without Faceplate
RGB/Component Video
MSX1616-1
MSX1616-5
RGB/Component Video + Balanced Stereo Audio
MSX1616-2
MSX1616-6
RGBHV MSX1616-3
MSX1616-7
RGBHV + Balanced Stereo Audio
MSX1616-4
MSX1616-8
16 x 16 Matrix Switcher 475 MHz
With Faceplate
Without Faceplate
RGB/Component Video
MSX1616HR-1
MSX1616HR-5
RGB/Component Video + Balanced Stereo Audio
MSX1616HR-2
MSX1616HR-6
RGBHV MSX1616HR-3
MSX1616HR-7
RGBHV + Balanced Stereo Audio
MSX1616HR-4
MSX1616HR-8
