32
MSX1616 OPERATION MANUAL - v1.0 5/8/02
2002 - INLINE, INC.
COMMAND
DESCRIPTION
[VINiix]
Increments/decrements input volume level for a specific
input.
•
Where
o
ii = 01 – 16 for input
o
x = + (plus sign) to increment input
volume
o
x = - (minus sign) to decrement input
volume
o
x = @ to return input volume to factory
default (0 dB)
o
x = ? to request current volume level
[VINiixxx]
Increments/decrements input volume level for a specific
input.
•
Where
o
oo = 01 – 16 for input
o
xxx = -640 - 0
Note: 0 equals max (+0.0 db), -640 equals minimum
(-55.0 dB)
[LMUTE,a,b,c,d,e,f,g,h,I,j,k,l,m,n
,o,p,]
Preload mute state for all outputs.
Must send a [TAKE] command to execute changes.
•
Where
o
a = 0 to disable, 1 to enable for output 1
o
b = 0 to disable, 1 to enable for output 2
o
c = 0 to disable, 1 to enable for output 3
o
d = 0 to disable, 1 to enable for output 4
o
e = 0 to disable, 1 to enable for output 5
o
f = 0 to disable, 1 to enable for output 6
o
g = 0 to disable, 1 to enable for output 7
o
h = 0 to disable, 1 to enable for output 8
o
etc.
[LMUTE,?]
Queries all LMUTE commands.
[LVOL,aaa,bbb,ccc,ddd,ee,efff,gg
g,hhh,iii,jjj,kk,lll,mmm,nnn,ooo,p
pp]
Preload output volume level for all outputs.
Must send a [TAKE] command to execute changes.
•
Where
o
aaa = -550 to 90 for output 1
o
bbb = -550 to 90 for output 2
o
ccc = -550 to 90 for output 3
o
ddd = -550 to 90 for output 4
o
eee = -550 to 90 for output 5
o
fff = -550 to 90 for output 6
o
ggg = -550 to 90 for output 7
o
hhh = -550 to 90 for output 8
o
etc.
Note: Level is set in .5 dB steps. For example, –23.5dB
is entered as -235
[LVOL,?]
Queries any previously loaded LVOL commands.
