MSX1616 Matrix Switcher - Quick Start, continued


Front Panel Controls


Buttons to the left of the LCD let you
navigate through the LCD menu options.

Arrowed buttons let you increase or
decrease a selection, scroll up or down,
move forward and backward, and change
inputs and outputs.

MENU displays the status menu on the
initial press. Subsequent presses display the
next menu level up.

ENTER saves newly selected menu
settings.

VOLUME adjusts the volume of the
selected audio output or input.

MUTE silences the selected audio output.

INPUT and OUTPUT buttons configure
any number of new patches.

TAKE performs the input-to-output
switches as configured.

PRESET recalls a preset configuration,
which includes all input/output patches and
volume levels.

BLANK acts as an input when creating
patches. Use it to blank any or all outputs.

CANCEL deletes unsaved configurations.

Functionality

Creating new patches

1. Press the button of the desired input

device.

2. Press the button(s) of the output(s)

where you want the input signal
sent.

3. Repeat steps 1 and 2 until all

connections are defined.

4. Press

TAKE to perform the patches.


Alternately, use the LCD menu.

Adjusting audio levels

1. Use

the

VOLUME buttons on the

front panel to increase or decrease
volume level for the currently
selected output.

2. Press

MUTE to silence the audio

output.

Creating a preset

1. Set all desired input/output patches,

audio levels, and mute states.

2. Press

MENU.

3. Select

3UHVHW 6WRUH on the

LCD.

4. Press any one of the input or output

buttons to select a storage location
for this preset.
Result: The switcher stores the
current configuration into memory.

Viewing switches

1. On the LCD Menu, select

3UHYLHZ.

2. Select and press an input or output

button to see all current switches.
Result: The LED indicators above
each button glow to indicate all
stored patches for those
inputs/outputs.
