34

MSX1616 OPERATION MANUAL - v1.0 5/8/02

2002 - INLINE, INC.

COMMAND

DESCRIPTION

[PCHpIiiabcde]
[PCHp
Iii?]

Loads hex command string to an input up to 60 characters.

Where

o

p = 2 for port 2, 3 for port 3

o

ii = 01 – 16 for input

o

abcdef… = hex string to be stored

o

abcdef = ?, queries current label

[PCHpOooabcde]
[PCHp
Ooo?]

Loads hex command string to an output up to 60 characters.

Where

o

p = 2 for port 2, 3 for port 3

o

oo = 01 – 16 for output

o

abcdef… = hex string to be stored

o

abcdef - ?, queries current label

[PCHpPmmmabcde]
[PCHp
Pmmm?]

Loads hex command string to a preset up to 60 characters.

Where

o

p = 2 for port 2, 3 for port 3

o

mmm = 001 - 256 for preset

o

abcdef… = hex string to be stored

o

abcdef - ?, queries current label

[PCLpIiiabcde]
[PCLp
Iii?]

Loads ASCII command string to an input up to 60 characters.

Where

o

p = 2 for port 2, 3 for port 3

o

ii = 01 – 16 for input

o

abcdef… = hex string to be stored

o

abcdef - ?, queries current label

Note: When controlling Inline products that also use brackets
as delimiters, replace open bracket [ with ‘ and closed bracket
] with " in the abcde… portion of the command. When this
command is sent out the command port the ‘will automatically
be replaced with []. "

[PCLpOooabcde]
[PCLp
Ooo?]

Loads ASCII command string to an output up to 60 characters.

Where

o

p = 2 for port 2, 3 for port 3

o

oo = 01 – 16 for output

o

abcdef… = hex string to be stored

o

abcdef - ?, queries current label

Note: When controlling Inline products that also use brackets
as delimiters, replace open bracket [with ‘ and closed bracket]
with " in the abcde… portion of the command. When this
command is sent out the command port the ‘ " will
automatically be replaced with [ ].
