FOX 500 DA6 • Reference Information
Reference Information, cont’d
FOX 500 DA6 • Reference Information A-6 A-7
Part Numbers
FOX 500 DA6 part numbers
The FOX 500 DA6 is available in a singlemode (SM) and a
multimode (MM) model:
FOX 500 Models Part number
FOX 500 DA6 SM 60-863-02
FOX 500 DA6 MM 60-863-01
Included parts
These items are included in each order for a FOX 500 DA6:
Included parts Part number
IEC power cord
Tweeker (small screwdriver)
User’s manual
Extron Software Products CD
(FOX 500 Control Program)
Captive screw 5-pole connectors (qty. 6)
10-703-12
(1) 10' LC-LC duplex patch cables
(SM or MM, depending on the model)
Compatible equipment
The FOX 500 DA6 is compatible with a variety of Extron fiber
optic receivers and matrix switchers, as shown below:
FOX 500 (RGB Video) receivers Part number
FOX 500 Rx SM 60-746-22
FOX 500 Rx MM 60-746-21
FOX 500 DVI models Part number
FOX 500 DVI Rx SM 60-859-22
FOX 500 DVI Rx MM 60-859-21
Fiber Matrix 6400 matrix switcher Part number
Fiber Matrix 6400 BME 60-878-01
Singlemode I/O card 60-879-02
Fiber Matrix 6400 matrix switcher Part number
Multimode I/O card 60-879-01
Optional accessory
Accessories Part number
9-pin D to 2.5 mm mini jack TRS RS-232
cable
70-335-01
Cables
Accessories Part number
VGA M-M MD ,
3' to 100' (0.9 m to 30.4 m) (molded)
26-238-nn
VGA M-M BK ,
3' to 100' (0.9 m to 30.4 m) (backshell)
26-238-nn
VGAP M-M MD ,
3' to 25' (0.9 m to 7.6 m) (molded)
26-439-nn
VGAP M-M BK ,
35' to 100' (10.6 m to 30.4 m) (backshell)
26-439-nn
VGA-A M-M MD (with audio) ,
3' to 50' (0.9 m to 15.2 m) (molded)
26-490-nn
VGA-A M-M BK (with audio) ,
3' to 50' (0.9 m to 15.2 m) (backshell)
26-490-nn
MHR-5 BNC mini high resolution
male to male, 3' to 100' (0.9 m to 30.4 m)
26-260-nn
MHR-5P BNC mini high resolution plenum
male to male, 3' to 100' (0.9 m to 30.4 m)
26-378-nn
M59-5 BNC mini 59 flex
male to male, 3' to 100' (0.9 m to 30.4 m)
26-499-nn
RG6-5 BNC super high resolution
male to male, 3' to 100' (0.9 m to 30.4 m)
26-369-nn
