FOX 500 DA6 • Remote Control
Remote Control, cont’d
3-10 FOX 500 DA6 • Remote Control 3-11
Command
ASCII Command (host to unit)
Response (unit to host)
Additional description
Total pixels
Set a total pixel value
11*
X&
#
Tpx
X&]
Set the total pixels to a specific value.
Example:
11*1555#
Tpx1555
]
Set the total pixel value to 1555.
Incr
ement total pixel value
+1
1#
Tpx
X&]
Incr
ease total pixel value by 1 pixel.
Decr
ement total pixel value
-1
1#
Tpx
X&]
Decr
ease total pixel value by 1 pixel.
Show total pixel value
11#
Tpx
X&]
List sync fr
equency
V
iew input fr
equency
1LS
X*
,
X*]
List the input fr
equency as
X*
kHz (horizontal) and
X*
Hz (vertical.
Memory pr
esets
Save pr
eset
X(
,
Spr
X(]
Command code is a comma.
Recall pr
eset
X(
.
Rpr
X(]
Command code is a period.
Command/r
esponse table for SIS commands (continued)
Command
ASCII Command (host to unit)
Response (unit to host)
Additional description
Audio input gain and attenuation
N
The
set
gain
(G
) and
attenuation
(g
) commands
ar
e
case
sensitive.
Set input audio gain to + dB value
X1)
G
Aud
X1@]
Example:
2G
Aud+02.0
]
Set the input audio gain to +2 dB.
Set input audio attenuation to - dB value
X1!
g
Aud
X1@]
Incr
ement level
+G
Aud
X1@]
Incr
ease audio level by 1.0 dB.
Example:
+G
Aud+03
]
Incr
ement the audio input level fr
om +2 dB to +3 dB.
Decr
ement level
-G
Aud
X1@]
Decr
ease the audio level by 1.0 dB.
Example:
-G
Aud-09
]
Decr
ement audio input level fr
om -08 dB to -9 dB.
Show input gain
G
X1@]
Audio output level
Set to consumer level
40*0#
Lvl0
]
Set the DA's audio output to the consumer (–10 dBV) level.
Set to pr
ofessional level
40*1#
Lvl1
]
Set the DA's audio output to the pr
ofessional (+4 dBu)
level.
Show audio output level
40#
X1#]
0 = consumer
, 1 = pr
ofessional.
Command/r
esponse table for SIS commands (continued)
