FOX 500 DA6 • Reference Information
Reference Information, cont’d
FOX 500 DA6 • Reference Information A-4 A-5
Frequency response ..................... 20 Hz to 20 kHz, ±0.5 dB
THD + Noise ................................. 0.10% @ 1 kHz at nominal level
S/N ................................................. >80 dB at maximum output (unweighted)
CMRR ............................................. 65 dB @ 20 Hz to 20 kHz
Audio bits per sample .................. 18 bits per channel, 2 channels (L, R)
Sampling rate ................................. 48 kHz
Audio input
Number/signal type .................... 2 inputs (mixed): 1 balanced stereo;
1 unbalanced stereo or 2 unbalanced mono
Connectors .................................... (1) 3.5 mm captive screw connector, 5 pole
(1) 3.5 mm mini stereo jack
Impedance ..................................... 18k ohms unbalanced,
20k ohms balanced, DC coupled
Nominal level ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................. +17 dBV, (unbalanced) at 1% THD+N
N 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV 2 dBu
Audio output — See FOX 500 Rx receiver specifica-
tions.
Control/remote
Serial control ports
Control ................................ 1 RS-232, 3.5 mm captive screw connector,
5 pole (3 pins are used) (rear panel)
1 RS-232, 2.5 mm mini stereo jack (front
panel)
Pass-through ...................... 1 RS-232, 3.5 mm captive screw connector,
5 pole (3 pins are used) (rear panel); in
parallel with 1 RS-232, 2.5 mm mini stereo
jack (front panel)
Baud rate and protocol
Control ................................ 9600 baud, 8 data bits, 1 stop bit, no parity
Pass-through ...................... 9600 to 38400 baud
Serial control pin configurations
Captive screw connectors:
1 = Tx, 2 = Rx, 3 = GND
Mini stereo jack: tip = Tx, ring = Rx,
sleeve = GND
Program control ............................. Extron’s control/configuration program
for Windows ®
Extron’s Simple Instruction Set (SIS ™ )
General
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 11 watts,
internal
Temperature/humidity ................ Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Cooling ........................................... Convection, vented, vents on top and side
panels
Rack mount .................................... Yes, with included brackets
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.7” H x 17.4” W x 9.5” D
(1U high, full rack wide)
4.3 cm H x 44.2 cm W x 24.1 cm D
(Depth excludes connectors.)
Product weight .............................. 3.9 lbs (1.8 kg)
Shipping weight ........................... 7 lbs (4 kg)
DIM weight
USA/Canada ..................... 7 lbs (4 kg)
International ....................... 8 lbs (4 kg)
Vibration ........................................ ISTA 1A in carton
(International Safe Transit Association)
Listings............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES,
FDA Class 1
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
