FOX 500 DA6 • Installation and Operation
Installation and Operation, cont’d
2-12
FOX 500 DA6
System Operation
After the DA, the receiver(s), and their connected devices are
powered up, the system is fully operational. If any problems are
encountered, ensure all traditional and fiber cables are routed
and connected properly:
• Ensure that the video source and the display(s) are
properly connected to the DA and the receiver(s), and that
the source, the DA, the receiver(s), and the display(s) have
power applied.
• Ensure that the signal monitoring LEDs (item b on
page 2-11) are indicating correctly for your system
configuration.
N If problems persist, call the Extron S3 Sales & Technical
Support Hotline.
3
Chapter Three
Remote Control
Rear.Panel.Remote.RS-232.Ports
Front.Panel.Configuration.Port
Simple.Instruction.Set.Control
Windows ® -Based.Program.Control
