FOX 500 DA6 • Remote Control
Remote Control, cont’d
3-14 FOX 500 DA6 • Remote Control 3-15
Command
ASCII Command (host to unit)
Response (unit to host)
Additional description
Information r
equests
Information r
equest
I
1Link
X1^
•2Link
X1^
•RGB
X1^
•Aud
X1^
•
X1&
•
X1*]
The unit r
esponds with the curr
ent status (signal
detected) of optical link 1, optical link 2, the video input, the audio input, the fiber optic mode (singlemode or multimode), and the device type (Tx or Rx).
N
The
master
r
eceiver
monitors
the
fiber
1
cable.
If
the
PC
is
connected
to
the
DA
and
fiber
cable
2
is
not
installed
bewtween
the
DA
and
the
master
r
eceiver
, for
the
information
r
equest
(I)
and
Status
commands
(S)
below
, the
DA
r
eports
1Link0
r
egardless
of
the
status
of
the
fiber
1
cable.
Show firmwar
e version
Q
X1%]
Example:
Q
1.23
]
The factory-installed FOX 500 contr
oller firmwar
e version
is 1.23 (sample value only).
Request part number
N
60-
nnn
-nn
]
See appendix
A
for part numbers.
Show link 1 status
1S
X1^]
0 = light link not r
eceived at r
eceiver
, 1 = light r
eceived.
Show link 2 status
2S
X1^]
0 = light link not r
eceived at DA, 1 = light r
eceived.
Show input video status
3S
X1^]
0 = video is not input to the DA, 1 = video is input.
Show input audio status
4S
X1^]
0 = audio is not input to the DA, 1 = audio is input.
Command/r
esponse table for SIS commands (continued)
Command
ASCII Command (host to unit)
Response (unit to host)
Additional description
Resets
Reset audio gain and attenuation
E
ZA
}
Zpa
]
Reset all audio settings to default (0 dB gain and consumer [-10 dB] level).
Reset pr
esets
E
ZG
}
Zpg
]
Reset (erase) all memory pr
esets.
System r
eset
E
ZXXX
}
Zpx
]
Reset all settings to the factory defaults.
Command/r
esponse table for SIS commands (continued)
