FOX 500 DA6 • Reference Information
Reference Information
FOX 500 DA6 • Reference Information A-2 A-3
Specifications
N The analog RGB input signal is digitized pixel for pixel in the
transmitter, sent digitally through the fiber cable, and converted
back to analog RGB in the receiver.
N The analog audio signal(s) is (are) digitized in the transmitter,
sent through the fiber cable, and converted back to analog audio
in the receiver.
Optical specifications
Number/type ................................ 6 fiber optic outputs
N Only one fiber is required to transmit video, audio, and
unidirectional data. A second fiber is required to transmit return
data for bidirectional control/communication on receiver 1.
Connectors ..................................... 6 LC connectors
Operating distance ........................ 30 km (18.75 miles) with singlemode (SM)
cables with a FOX 500 DA6 SM
0.15 km (492’) with multimode (MM)
cables with a FOX 500 DA6 MM
N Operating distance is approximate. These are typical
distances. The maximum distance may be greater than these
typical numbers depending on factors such as fiber type, fiber
bandwidth, connector splicing, losses, modal or chromatic
dispersion, environmental factors, and kinks.
Nominal peak wavelength........... 850 nm for FOX 500 DA6 MM,
1310 nm for FOX 500 DA6 SM
Data rate ......................................... 4.25 Gbps
Transmission power
Singlemode ......................... -5 dBm, typical
Multimode .......................... -5 dBm, typical
Maximum receiver sensitivity
Singlemode ......................... -18 dBm, typical
Multimode .......................... -12 dBm, typical
Optical loss budget
Singlemode ......................... 13 dB, maximum
Multimode .......................... 7 dB, maximum
Video
Gain ................................................ Unity
Pixel data bit depth ....................... 8 bits per channel, 3 channels (R, G, B)
Maximum resolution .................... 1600x1200 @ 60 Hz, digitized pixel by
pixel; higher resolutions up to 2048x1120,
undersampled
Video input and loop-through
Number/signal type ..................... 1 VGA-UXGA RGBHV, RGBS, RGsB,
RsGsBs input
1 VGA-UXGA RGBHV, RGBS, RGsB,
RsGsBs loop-through
Connectors .................................... 1 x 5 female BNC or (1) female 15-pin HD
for input
(1) female 15-pin HD for loop-through
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ..................................... 75 ohms
Horizontal frequency .................... 24 kHz to 100 kHz
Vertical frequency .......................... 40 Hz to 120 Hz
Return loss ..................................... <-40 dB @ 5 MHz
N These transceivers are class 1 laser products. They meet the
safety regulations of IEC-60825, FDA 21, CFR 1040.10, and
FDA 21 CFR 1040.11.
Video output — See optical specifications above.
Sync
Input type ...................................... Autodetect RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... 2.5 V to 5.0 Vp-p
Input impedance .......................... 10k ohms
Polarity............................................ Positive or negative (follows input or can
be set by user)
Audio
Gain
Range ................................. Adjustable, -18 dB to +10 dB
Default
Captive screw connector
Unbalanced output: -6 dB;
balanced output: 0 dB
Mini stereo jack .......... Unbalanced output: 0 dB
