9 FIELD BUS 9 FIELD BUS 9 FIELD BUS 9 FIELD BUS
List of the main available Modbus R (Read) and R/W (Read/Write) parameters
ADDRESS DESCRIPTION RANGE DEFAULT
40003 ANALOG OUTPUT value R
40004 AN. INPUT AI1 value R
40005 AN. INPUT AI2 value R
40021 DIGITAL INPUT status R
40032 P1 STOP THRESHOLD R/W 350
40033 P1 START THRESHOLD R/W 270
40034 P2 STOP THRESHOLD R/W 340
40035 P2 START THRESHOLD R/W 260
40036 P3 STOP THRESHOLD R/W 330
40037 P3 START THRESHOLD R/W 250
40041 P1 START DELAY R/W 003
40043 P2-3 START DELAY R/W 005
40044 P1 STOP DELAY R/W 005
40045 P2-3 STOP DELAY R/W 003
40121 DAY (AUTOTEST) R/W 0=Monday, 1=Tuesday,
2=Wednesday, 3=Thursday, 4=Friday,
5=Saturday, 6=Sunday 0
40122 HOUR (AUTOTEST) R/W 10
40123 MINUTES (AUTOTEST) R/W 00
40124 NIGHT/DAY FUNCTION R/W 0=disabled, 1=by int. clock,
2=by ext. control, 3=by int. and ext.
control 0
40125 NIGHT/DAY VALUE R/W 100
40126 N/D START HOUR R/W
40127 N/D START MINUTES R/W
40128 N/D END HOUR R/W
40129 N/D END MINUTES R/W
40130 RS485 MODBUS ENABLE R/W 0= disabled, 1=enabled 1
40131 MODBUS ADDRESS R/W
40132 PARITY R/W 0=none, 1=even, 2= odd 0
40133 DELAY R/W
40134 BAUD RATE R/W 0=1200, 1=2400, 2=4800,
3=6900, 4=19200, 5=38400,
6=57600, 7=115200 5
40135 P1 OPERAT.HOURS R
40136 P2 OPERAT.HOURS R
40137 P3 OPERAT.HOURS R
40138 ALARMS LOG: type 1 st trip R 0=flash init. error, 1=f.ram
init.error, 2= LOW WATER alarm, 3=
SENSOR 1 alarm, 4= SENSOR 2 alarm,
5=OVERLOAD 1, 6=OVERLOAD 2, 7=
OVERLOAD 3, 8= AUTOTEST FAIL P1,
9=AUTOTEST FAIL P2, 10= AUTOTEST
FAIL P3, 11=CONVEYOR LIMIT,
12=HIGH PRESSURE,
13=MAX.PRES.THRESH. alarm,
14=MIN.PRES.THRESH. alarm
