49
4 REL.OUT4 CONFIG Allows you to configure the OUT_4
relay of the RILS6 optional board See
configuration 1 THERMAL
PR.
5 REL.OUT5 CONFIG Allows you to configure the OUT_5
relay of the RILS6 optional board See
configuration 1 LEVEL
6 REL.OUT6 CONFIG Allows you to configure the OUT_6
relay of the RILS6 optional board See
configuration 1 POWER ON
6.2.14 DEFAULT PARAMETERS
6.2.14 DEFAULT PARAMETERS 6.2.14 DEFAULT PARAMETERS 6.2.14 DEFAULT PARAMETERS
Phase Display Comment Field Default
0 0 0 0 DEFAULT DEFAULT DEFAULT DEFAULT
1 DEFAULT PARAMETER Loads all the default parameters (factory
setting) YES
NO
6.2.15 PROGRAMMING THE CLOCK 6.2.15 PROGRAMMING THE CLOCK 6.2.15 PROGRAMMING THE CLOCK 6.2.15 PROGRAMMING THE CLOCK
Phase Display Comment Field Default
0 0 0 0 REAL TIME CLOC REAL TIME CLOC REAL TIME CLOC REAL TIME CLOCK K K K
1 SET DATE Setting the date Day
Month
Year
2 SET HOUR Setting the hour and the minutes Hour +
Minutes
6.2.16 CONFIGURING THE DISPLAY
6.2.16 CONFIGURING THE DISPLAY 6.2.16 CONFIGURING THE DISPLAY 6.2.16 CONFIGURING THE DISPLAY
Phase Display Comment Field Default
0 0 0 0 DISPLAY DISPLAY DISPLAY DISPLAY
1 AI1 DISPLAY The display shows the value of AI1 YES
NO YES
2 AI2 DISPLAY The display shows the value of AI2 YES
NO YES
3 HOUR/DATE DISPL. The display shows the value of the date
and time YES
NO NO
4 BARGRAPH Enables display of the indicating bar on
input selected as feedback.
Available only on systems with sensors. YES
NO NO
6.2.17 SOFTWARE
6.2.17 SOFTWARE 6.2.17 SOFTWARE 6.2.17 SOFTWARE
Phase
Display Comment Field Default
0 0 0 0 SOFTWARE SOFTWARE SOFTWARE SOFTWARE
1 VERSION Only reading of program loaded and
release number BSETF3
REL .01
