47
3 AI1 FILTER Software filter (no. samples) of the
analog input AI1 signal 1..199 1
4 AI1 UNIT Setting the unit of measurement on
input AI1 DISABLED
bar
°C
m³/h
m
bar
5 AI2 SENSOR TYPE Type of transducer connected to the
analog input AI2 (if selected on System) 4-20 mA
0-20 mA
0-10 V
0-2 V 4-20 mA
6 ZERO ADJUST AI2
Visible only if 4-20mA selected.
Acquisition of input zero 4 4-20 mA
Adjustment is possible only in the range
3.5… 4.5mA
If adjustment has a positive result the
message SENSOR ADJUST OK appears
If out of range the message SENSOR
ADJUST KO appears YES
NO NO
7 AI2 FILTER
Software filter (no. samples) of the
analog input AI2 signal 1..199 1
8 AI2 UNIT Setting the unit of measurement on
input AI2 DISABLED
bar
°C
m³/h
m
bar
9 ANALOG OUTPUT Function that can be attributed to analog
output Out_A DISABLED
AI1
AI2 DISABLED
10 AN.OUT1 TYPE Full scale analog output AO1 4-20 mA
0-20 mA
0-10 V
0-2 V 4-20 mA
6.2.11 PROGRAMMING DIGITAL INPUTS / OUTPUTS
6.2.11 PROGRAMMING DIGITAL INPUTS / OUTPUTS 6.2.11 PROGRAMMING DIGITAL INPUTS / OUTPUTS 6.2.11 PROGRAMMING DIGITAL INPUTS / OUTPUTS
Phase Display Comment Field Default
0 0 0 0 DIGITAL IN / OUT DIGITAL IN / OUT DIGITAL IN / OUT DIGITAL IN / OUT
1 PR.SW.1 LOGIC Terminal 2 only if pressure switch
operation enabled. NC / NO NC
2 PR.SW.2 LOG Terminal 3 only if pressure switch
operation enabled. NC / NO NC
3 PR.SW.3 LOGIC Terminal 4 only if pressure switch
operation enabled. NC / NO NC
4 CONFIG. AUX1 IN.
Configuration of input AUX1 as max.
pressure pressure-switch or external
auto-test command. DISABLED
HIGH
PRESSURE
START
AUTOTEST DISABLED
5 CONFIG. AUX2 IN. Configuration of input AUX2 as external
consent (NO) or external alarm (NC). DISABLED
EXT.ALARM
EXT.ON/OFF DISABLED
