CONFIG. AUX3 IN. Configuration of input AUX3 as
change set (NO) or minimum
pressure switch CONV.L.SWITCH DISABLED
CHANGE SET
CONV.L.SWITCH CONV.L.SWIT
CH
7 AUX1 IN DELAY Delay time in seconds till
activation of input AUX1.
Visible only if AUX1 is enabled. 0..20 s 0 s
8 AUX2 IN DELAY Delay time in seconds till
activation of input AUX2.
Visible only if AUX2 is enabled. 0..20 s 0 s
9 AUX3 IN DELAY Delay time in seconds till
activation of input AUX3.
Visible only if AUX3 is enabled. 0..20 s 0 s
6.2.12 PROGRAMMING FIELD BUS RS485
6.2.12 PROGRAMMING FIELD BUS RS485 6.2.12 PROGRAMMING FIELD BUS RS485 6.2.12 PROGRAMMING FIELD BUS RS485
Phase Display Comment Field Default
0 0 0 0 FIELD BUS FIELD BUS FIELD BUS FIELD BUS
1 RS485 ENABLE Enable YES
NO YES
2 MODBUS ADDRESS 1:31 1
3 PARITY None
Even
Odd None
4 DELAY 0..199 ms 0
5 BAUD RATE 1200
2400
4800
9600
19200
38400
57600
115200 38400
6.2.13 RILS6 BOARD RELAY CONFIGURATION RELAUNCH CLEAN CONTACTS SIGNALS 6.2.13 RILS6 BOARD RELAY CONFIGURATION RELAUNCH CLEAN CONTACTS SIGNALS 6.2.13 RILS6 BOARD RELAY CONFIGURATION RELAUNCH CLEAN CONTACTS SIGNALS 6.2.13 RILS6 BOARD RELAY CONFIGURATION RELAUNCH CLEAN CONTACTS SIGNALS
Phase
Display Comment Field Default
0 0 0 0 RILS6 CONFIG. RILS6 CONFIG. RILS6 CONFIG. RILS6 CONFIG.
1 REL.OUT1 CONFIG
Allows you to configure the OUT_1
relay of the RILS6 optional board AUT - MAN
P1
P2
P3
THERMAL PR.
LEVEL
MAX P
MIN P
EXT.AL.
AUTOP.KO
POWER ON
P1
2 REL.OUT2 CONFIG Allows you to configure the OUT_2
relay of the RILS6 optional board See
configuration 1 P2
3 REL.OUT3 CONFIG Allows you to configure the OUT_3
relay of the RILS6 optional board See
configuration 1 P3
