SAFETY WARNINGS FOR PERSONS AND PROPERTY SAFETY WARNINGS FOR PERSONS AND PROPERTY SAFETY WARNINGS FOR PERSONS AND PROPERTY SAFETY WARNINGS FOR PERSONS AND PROPERTY
The symbols used are shown below
ENGLISH INSTRUCTIONS INDEX ENGLISH INSTRUCTIONS INDEX ENGLISH INSTRUCTIONS INDEX ENGLISH INSTRUCTIONS INDEX
1 GENERAL INFORMATION 31
2 PRODUCT DESCRIPTION 31
3 OPERATION 31
4 INSTALLATION 33
5 GENERAL SETTINGS 36
6 PROGRAMMING 37
7 ALARMS 50
8 PARAMETER STRUCTURE 52
9 FIELD BUS 53
10 ELECTRONIC BOARD MAINTENANCE 54
11- REPAIRS - SPARE PARTS 54
12 TROUBLESHOOTING 55
13 TAKING OUT OF SERVICE 55
This manual consists of two parts, the first is intended for the installer and the user, the second only for
the installer.
Before starting installation, read these instructions carefully and abide by local regulations.
Installation and maintenance must be carried out by qualified personnel.
The booster set is an automatic machine, the pumps may start automatically without warning.
The set contains water under pressure, reduce the pressure to zero before intervention.
Make the electrical connections in compliance with the regulations.
Ensure that there is an efficient earth system.
Before doing any work on the set, disconnect the electric power supply.
If the set is damaged, disconnect the electric power supply to avoid electric shocks.
CAUTION CAUTION CAUTION CAUTION
DANGER
Risk of injury to persons and property if the requirements are not
observed.
ELECTRIC SHOCK
Risk of electric shock if the requirements are not observed.
WARNING
Risk of damage to property or to the environment if the
requirements are not observed.
