GigaX Series L2 Managed Switch User Guide
4.5.3 Static Multicast
This page can add multicast addresses into the multicast table. The switch
can hold up to 256 multicast entries. All the ports in the group will forward
the specified multicast packets to other ports in the group.
Show Group: selects “Add a new Group” to enter a new entry, or
select an existing group address to display
MAC Address: selects the multicast address
VLAN: selects the VLAN group
CoS: assigns the priority for Class of Service
Click to make the setting effective. Click to refresh the
settings to current value.
Figure 27. Static Multicast (GigaX 2048)
