GigaX Series L2 Managed Switch User’s Guide
142
exceed act(none/drop/dscp):
exceed dscp(0/8/10/16/18/24/26/32/34/40/46/48/56):
[Modify]
Allows users to modify a policy action by specifying a policy ID and class ID.
CLI command: qos policy add
dscp (old dscp value):
traffic rate(old traffic rate):
traffic burst size(old traffic rate size):
exceed act(old exceed action):
exceed dscp(old dscp value):
[Remove]
Allows users to remove a policy action by specifying a policy ID and class ID.
Users can remove all policy actions of a policy by specifying a policy ID and ‘*’.
CLI command: qos policy remove classes>
[Policy ID]
[Attach/Detach]
To attach or detach a policy to ingress ports.
CLI command: qos policy attach
CLI command: qos policy detach
[Retrieve]
Restores the previous saved settings from configuration file.
CLI command: qos retrieve
[Scheduling Algorithm]
[CoS Queue ][Weight]
Set the schedule mode. The weight delay of queues only effective for weighted
round robin and bounded delay. The range of weight delay is 1-255.
CLI command: l2 cos sched 3:bounded delay)>
