GigaX Series L2 Managed Switch User’s Guide
114
[Create Trunk]
Creates a new trunk group by giving trunk ID, rtag, name, LACP mode and
port numbers. The “rtag” is the packet distribution algorithm for the trunk
group.
Rtag values and corresponding meanings:
1: select port by source MAC
2: select port by destination MAC
3: select port by source and destination MAC
4: select port by source IP
5: select port by destination IP
6: select port by source and destination IP
CLI command: l2 trunk create name>
[Add/Remove Trunk]
Trunk group port members can be added to or removed from an existing
trunk group.
CLI command: l2 trunk add
CLI command: l2 trunk remove
[LACP Action]
User can enable or disable LACP on a specific trunk group.
CLI command: l2 trunk lacp action
[LACP System Priority]
User can assign the system priority for running LACP.
CLI command: l2 trunk lacp syspri
