4.4.2

LAN Cable Status

This menu displays the status of the Local Area Network (LAN) cable
connected to the LAN (RJ-45) port.

POST Check LAN Cable [Disabled]

Allows you to enable or disable LAN cable check during POST. When
enabled, the menu reports the cable faults or shorts, and displays the point
(length) where the fault or short is detected.
Configuration options: [Disabled] [Enabled]

POST Check LAN Cable

[Disabled]

LAN Cable Status
Pair Status Length

1-2 Normal

N/A

3-6 Normal

N/A

4-5 Normal

N/A

7-8 Normal

N/A

1-2 Open

0.0M

3-6 Open

0.0M

4-5 Open

0.0M

7-8 Open

0.0M

Check LAN cable
during POST.

Target Frequency [Overclock 3%]

Allows you to set the maximum overclock percentage for the selected NOS
Mode. Configuration options: [Overclock 3%] [Overclock 5%] [Overclock
7%] [Overclock 10%] [Overclock 15%] [Overclock 20%] [Overclock 30%]

Selecting a very high frequency may cause the system to become
unstable. If this happens, revert to the default setting.

The following item appears only when you install a CPU that supports the
lock free feature. Only some latest CPUs support this feature

AI CPU Lock Free [Auto]

This feature allows you to let the processor run at a lower multiplier.
Setting this item to [Auto] allows the motherboard to automatically reduce
the CPU multiplier value for more flexibility when increasing external FSB.
Configuration options: [Auto] [Disabled] [Enabled]
