LAN Option ROM [Disabled]
This item allows you to enable or disable the option ROM in the
onboard LAN controller. This item appears only when the O n b o a r d
O n b o a r d O n b o a r d O n b o a r d O n b o a r d
P C I E G b E L A N _ 2 P C I E G b E L A N _ 2 P C I E G b E L A N _ 2 P C I E G b E L A N _ 2 P C I E G b E L A N _ 2 item is set to Enabled.
Configuration options: [Disabled] [Enabled]
Marvell SATA/PATA Controller [Enabled] Marvell SATA/PATA Controller [Enabled] Marvell SATA/PATA Controller [Enabled] Marvell SATA/PATA Controller [Enabled] Marvell SATA/PATA Controller [Enabled]
Allows you to enable or disable the the onboard Marvell ® Serial ATA and
Parallel ATA RAID controller. Configuration options: [Disabled] [Enabled]
SATA_Raid4 [E-SATA]
Sets the SATA_RAID4 connector lane assignment. Set to [E-SATA]
when using the external SATA port or [Int-SATA] to use the
SATA_RAID4 connector. Configuration options: [E-SATA] [Int-SATA]
M a r v e l l S A T A B O O T R O M [ D i s a b l e d ] M a r v e l l S A T A B O O T R O M [ D i s a b l e d ] M a r v e l l S A T A B O O T R O M [ D i s a b l e d ] M a r v e l l S A T A B O O T R O M [ D i s a b l e d ] M a r v e l l S A T A B O O T R O M [ D i s a b l e d ]
Enables or disables the Marvell SATA boot ROM.
Configuration options: [Disabled] [Enabled]
Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4] Serial Port1 Address [3F8/IRQ4]
Allows you to select the Serial Port1 base address. Configuration options:
[Disabled] [3F8/IRQ4] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378] Parallel Port Address [378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP] Parallel Port Mode [ECP]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-directional] [EPP] [ECP]
E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ] E C P M o d e D M A C h a n n e l [ D M A 3 ]
Appears only when the Parallel Port Mode is set to [ECP]. This item
allows you to set the Parallel Port ECP DMA.
Configuration options: [DMA0] [DMA1] [DMA3]
Parallel Port IRQ [IRQ7]
Allows you to select the parallel port IRQ.
Configuration options: [IRQ5] [IRQ7]
Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled] Onboard Game/MIDI Port [Disabled]
Allows you to select the Game Port address or to disable the port.
Configuration options: [Disabled] [200/300] [200/330] [208/300]
[208/330]
