2 - 6 2 - 6 2 - 6 2 - 6 2 - 6 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n
I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s I n t e r n a l c o n n e c t o r s P a g e P a g e P a g e P a g e P a g e
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-28
2. Marvell IDE connector (40-1 pin PRI_EIDE [red]) 2-28
3. ICH7R Primary IDE connector (40-1 pin PRI_IDE) 2-29
4. ICH7R Serial ATA connectors (7-pin SATA1 [red], 2-30
SATA2 [red], SATA3 [black], SATA4 [black])
5. Marvell 6141 Serial ATA connector 2-31
(7-pin SATA_RAID1[red], SATA_RAID2[red],
SATA_RAID3[red], SATA_RAID4[black])
6. Optical drive audio connector (4-pin CD) 2-32
7. Front panel audio connector (10-1 pin AAFP) 2-32
8. USB connectors (10-1 pin USB56, USB78_WFG) 2-33
9. IEEE 1394a port connectors (10-1 pin IE1394_1, IE1394_2) 2-33
10. GAME/MIDI port connector (16-1 pin GAME) 2-34
11. Chassis intrusion connector (4-1 pin CHASSIS) 2-34
12. CPU, Chassis, and Power fan connectors 2-35
(4-pin CPU_FAN, 3-pin PWR_FAN, 3-pin CHA_FAN1,
3-pin CHA_FAN2)
13. Serial port connector (10-1 pin COM1) 2-36
14. ATX power connectors (24-pin EATXPWR, 2-36
2 x 4-pin EATX12V, 4-pin EZ_PLUG)
15. System panel connector (20-pin PANEL) 2-39
• System power LED (Green 3-pin PLED)
• Hard disk drive activity LED (Red 2-pin IDE_LED)
• System warning speaker (Orange 4-pin SPEAKER)
• ATX power button/soft-off button (Yellow 2-pin PWRSW)
• Reset button (Blue 2-pin RESET)
