P5wd2-e premium specifications summary – Asus P5WD2-E Premium User Manual

Page 13

background image

x i i i

x i i i

x i i i

x i i i

x i i i

1 x Parallel port
1 x External Serial ATA port
2 x LAN (RJ-45) ports
4 x USB 2.0 ports
1 x Optical S/PDIF Out port
1 x Coaxial S/PDIF Out port
1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
8-channel audio ports

1 x Floppy disk drive connector
2 x IDE connectors
8 x Serial ATA connectors*
1 x Optical drive audio connector
1 x Front panel audio connector
2 x USB 2.0 connectors for four additional USB 2.0 ports
2 x IEEE 1394a connectors
1 x GAME/MIDI connector
1 x Serial port connector
ATX power connectors (24-pin and 2 x 4-pin)
ASUS EZ Plug™ connector
2 x Chassis fan connectors
CPU fan connector
Power fan connector
Chassis intrusion connector
System panel connector
(

*Note: The SATA_RAID4 connector and external SATA port

can not be used simultaneously.

)

Device drivers
ASUS Live Update
ASUS PC Probe 2
ASUS AI Booster
Microsoft

®

DirectX 9.0c

Adobe

®

Acrobat Reader

®

Anti-virus software (OEM version)

*Specifications are subject to change without notice.

R e a r p a n e l

R e a r p a n e l

R e a r p a n e l

R e a r p a n e l

R e a r p a n e l

I n t e r n a l

I n t e r n a l

I n t e r n a l

I n t e r n a l

I n t e r n a l
c o n n e c t o r s

c o n n e c t o r s

c o n n e c t o r s

c o n n e c t o r s

c o n n e c t o r s

S u p p o r t C D

S u p p o r t C D

S u p p o r t C D

S u p p o r t C D

S u p p o r t C D
c o n t e n t s

c o n t e n t s

c o n t e n t s

c o n t e n t s

c o n t e n t s

P5WD2-E Premium specifications summary
