2.5.3 2.5.3 2.5.3 2.5.3 2.5.3 Interrupt assignments Interrupt assignments Interrupt assignments Interrupt assignments Interrupt assignments
Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments Standard interrupt assignments
I R Q I R Q I R Q I R Q I R Q P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y P r i o r i t y S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n S t a n d a r d F u n c t i o n
0 1 System Timer
1 2 Keyboard Controller
2 — Re-direct to IRQ#9
3 11 IRQ holder for PCI steering*
4 12 Communications Port (COM1)*
5 13 IRQ holder for PCI steering*
6 14 Floppy Disk Controller
7 15 Printer Port (LPT1)*
8 3 System CMOS/Real Time Clock
9 4 IRQ holder for PCI steering*
10 5 IRQ holder for PCI steering*
11 6 IRQ holder for PCI steering*
12 7 PS/2 Compatible Mouse Port*
13 8 Numeric Data Processor
14 9 Primary IDE Channel
15 10 Secondary IDE Channel
* These IRQs are usually available for ISA or PCI devices.
IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard IRQ assignments for this motherboard
A A A A A B B B B B C C C C C D D D D D E EE EE F FF FF G G G G G H H H H H
PCI slot 1 — — — — — shared — —
PCI slot 2 — — — — — — shared —
PCI slot 3 — — — — — — — shared
Onboard IDE (Marvell) — shared — — — — — —
Onboard 1394 — — — — — shared — —
Onboard LAN1 — — — shared — — — —
Onboard LAN2 shared — — — — — — —
PCIE x16 1 shared — — — — — — —
PCIE x16 2 shared — — — — — — —
PCIE x4 shared — — — — — — —
PCIE x1 — — shared — — — — —
USB controller 1 — — — — shared — — —
USB controller 2 — shared — — — — — —
USB controller 3 — — shared — — — — —
USB controller 4 — — — shared — — — —
USB 2.0 controller — — — — shared — — —
Serial ATA — — — — — — — shared
IDE — — — — — — shared —
Azalia — — — shared — — — —
