U S B c o n n e c t o r ( 1 0 - 1 p i n U S B 5 6 , U S B 7 8 _ W F G )

These connectors are for USB 2.0 ports. Connect the USB/GAME
module cable to these connectors, then install the module to a slot
opening at the back of the system chassis. These USB connectors
comply with the USB 2.0 specification that supports up to 480 Mbps
connection speed.

Never connect a 1 3 9 4 c a b l e

1 3 9 4 c a b l e

1 3 9 4 c a b l e to the USB connectors. Doing so will

damage the motherboard!

9 .

I E E E 1 3 9 4

I E E E 1 3 9 4a

aa port connector

port connector

(10-1 pin IE1394_

(10-1 pin IE1394_1

1 [

[

[R e d

R e d

R e d]]]]], I E 1 3 9 4 _ 2 [ r e d ]

, I E 1 3 9 4 _ 2 [ r e d ]

, I E 1 3 9 4 _ 2 [ r e d ])))))

This connector is for an additional IEEE 1394a port. Connect the IEEE
1394a module cable (red) to this connector, then install the module
to a slot opening at the back of the system chassis.

Never connect a U S B p o r t m o d u l e c a b l e

U S B p o r t m o d u l e c a b l e

U S B p o r t m o d u l e c a b l e to the IEEE 1394

connector. Doing so will damage the motherboard!

P5WD2-E PREMIUM USB 2.0 Connectors

USB78_WFG

USB+5V

USB_P6-

USB_P6+

GND

USB+5V

USB_P5-

USB_P5+

GND

USB56

USB+5V

USB_P6

GND

USB+5V

USB_P5-

USB_P5+

GND

P5WD2-E

P5WD2-E PREMIUM IEEE 1394a Connectors

IE1394_1

GND

+12V

TPB1-

GND

A1-

+12V

TPB1+

GND

A1+

IE1394_2

GND

+12V

TPB1-

GND

A1-

+12V

TPB1+

GND

TPA1+
