2 - 3 2 2 - 3 2 2 - 3 2 2 - 3 2 2 - 3 2 C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n C h a p t e r 2 : H a r d w a r e i n f o r m a t i o n
7 . 7 . 7 . 7 . 7 . F r o n t p a n e l a u d i o c o n n e c t o r ( 1 0 - 1 p i n A A F P ) F r o n t p a n e l a u d i o c o n n e c t o r ( 1 0 - 1 p i n A A F P ) F r o n t p a n e l a u d i o c o n n e c t o r ( 1 0 - 1 p i n A A F P ) F r o n t p a n e l a u d i o c o n n e c t o r ( 1 0 - 1 p i n A A F P ) F r o n t p a n e l a u d i o c o n n e c t o r ( 1 0 - 1 p i n A A F P )
This connector is for a chassis-mounted front panel audio I/O module
that supports either HD Audio or legacy AC’97 audio standard.
• We recommend that you connect a high-definition front panel audio
module to this connector to avail the motherboard high-definition
audio capability.
• By default, this connector is set to HD Audio. If you want to connect
a legacy AC `97 front panel audio module to this connector, set the
F r o n t P a n e l S u p p o r t T y p e
F r o n t P a n e l S u p p o r t T y p e F r o n t P a n e l S u p p o r t T y p e F r o n t P a n e l S u p p o r t T y p e F r o n t P a n e l S u p p o r t T y p e item in the BIOS Setup to [AC97].
See page 4-30 for details.
6 . 6 . 6 . 6 . 6 . O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D ) O p t i c a l d r i v e a u d i o c o n n e c t o r ( 4 - p i n C D )
This connector is for the 4-pin audio cable that connects to the audio
connector at the back of the optical drive.
P5WD2-E PREMIUM Internal Audio Connector
CD
(black)
Right Audio Channel
Left Audio Channel
Ground
Ground
P5WD2-E
®
P5WD2-E PREMIUM Analog Front Panel Connector
AC ‘97 audio
pin definition
AAFP
NC
MIC2
Line out_R
Line out_L
NC
NC
MICPWR
NC
AGND
SENSE2_RETUR
PORT1 L
PORT2 R
PORT2 L
SENSE1_RETUR
SENSE_SEND
PORT1 R PRESENCE#
GND
P5WD2-E
®
