Asus RS320Q-E7/RS12 - Manual (Page 125)

6-31 ASUS RS320Q-E7/RS12
6.3.5 Recovery Volume Options
If you have created a recovery set, you can configure more recovery set options following the
descriptions in the section.
See section 5.3.2 Creating a Recovery set to create a recovery set before continue.
To configure a recovery set:
1. From the utility main menu, select 4. Recovery Volume Options and press .
The following screen appears.
2. Use the up/down arrow keys to select the option you want, and then press .
The SELECT RECOVERY VOLUME screen appears.
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-12 Intel Corporation. All Rights Reserved.
[ RECOVERY VOLUME OPTIONS ]
[ HELP ]
Enable Only Recovery Disk - enables recovery disk if available and
disables master disk.
Enable Only Master Disk - enables master disk if available and
disables recovery disk.
Actions will result in change from Continuous Update mode to On-Request.
[↑↓]-Select [ESC]-Previous Menu [ENTER]-Select
1. Enable Only Recovery Disk
2. Enable Only Master Disk
[ SELECT RECOVERY VOLUME ]
Name Level Capacity Status Bootable
Volume0 Recovery(Cont.) 149.0GB Normal Yes
Select a Recovery volume to do the operation.
[↑↓]-Up/Down [SPACE]-Selects [ENTER]-Done
3. Use the up/down arrow keys to select a drive, and then press to select. A
small triangle marks the selected drive. Press after completing your selection
and return to the utility main menu.
