ASUS RS120-E4/PA4

5-31

5.4.9.

Hardware.Monitor

Select Screen

Select Item

+- Change Option

F1 General Help

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.

This value stands

for the offset

temperatureto CPU1

defined TControl

CPU1 Temperature

[42..5ºC/108.5ºF]

System1 Temperature

[35ºC/95ºF]

System2 Temperature

[29ºC/84ºF]

Fan1 Speed

[12300RPM]

Fan2 Speed

[12134RPM]

Fan3 Speed

[12356RPM]

Fan4 Speed

[12646RPM]

Fan5 Speed

[12558RPM]

Fan6 Speed

[11842RPM]

Fan7 Speed

[11843RPM]

Fan8 Speed

[11838RPM]

Smart Fan Control

[Smart Fan II]

Offset to CPU1 TControl [0]

System1 Target Temperature[039]

VCORE1 Voltage

[ 1.265V]

VTT Voltage

[ 1.242V]

1.5V Voltage

[ 1.488V]

1.8V Voltage

[ 1.776V]

Advanced

CPU1.Temperature.[xxxºC/xxxºF].

System1/2.Temperature.[xxxºC/xxxºF]

The onboard hardware monitor automatically detects and displays the system and

CPU temperatures. Select [Disabled] if you do not wish to display the detected

temperatures.

Fan1/2/3/4/5/6/7/8.Speed.[xxxxRPM].or.[N/A]

The onboard hardware monitor automatically detects and displays the system and

device fan speeds in rotations per minute (RPM). If a fan is not connected to the

connector on the motherboard, the field shows [N/A].

Smart.Fan.Control.[Smart.Fan.II]

Allows you to enable or disable the ASUS Smart Fan Control feature that smartly

adjusts the fan speeds for more efficient system operation.

Configuration options: [Disabled] [Smart Fan] [Smart Fan II]

The

System.Target.Temperature.item does not appear when the Smart.Fan.

Control item is disabled.

Offset to CPU1 TControl [0]

Configuration options: [0]~[-25]

Scroll down to display the additional item.

F10 Save and Exit

ESC Exit

v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.

3V Voltage

[ 3.344V]

12V Voltage

[11.808V]

5V Voltage

[ 5.070V]

5VSB Voltage

[ 5.070V]

VBAT Voltage

[ 3.104V]
