ASUS RS120-E4/PA4 5-21
5.4.3 Chipset Configuration
The Chipset Configuration menu allows you to change the advanced chipset
settings. Select an item then press to display the sub-menu.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Configure North Bridge
features.
Advanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
North Bridge Configuration
South Bridge Configuration
Intel PCI-X Hub Configuration
Onboard PCIE LAN Boot ROM [Enabled]
NorthBridge Configuration
The NorthBridge Configuration menu allows you to change the Northbridge related
settings.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
ENABLE: Allow
remapping of
overlapped PCI memory
above the total
physical memory.
DISABLE: Do not allow
remapping of memory.
North Bridge Chipset Configuration
Memory Remap Feature [Enabled]
DRAM Frequency [Auto]
Configure DRAM Timing by SPD [Enabled]
Memory Remap Feature [Enabled]
Allows you to remap the overlap PCI memory over the total physical memory.
Configuration options: [Disabled] [Enabled]
DRAM Frequency [Auto]
Allows you to set the DDR operating frequency.
Configuration options: [Auto] [533 MHz] [667 MHz]
The DRAM.Frequency item becomes configurable when Configure DRAM
Timing.by.SPD item is set to [Disabled]
