5-14 Chapter 5: BIOS setup
ATA/IDE Configuration [Enhanced]
Allows selection of the IDE operation mode depending on the installed operating
system (OS). Set to [Enhanced] mode if you are using native OS, e.g.
Windows ® Server 2000/2003. Set to [Compatible] mode if you are using legacy OS,
e.g. Windows ME/98/NT, MS-DOS.
Configuration options: [Disabled] [Compatible] [Enhanced]
The Configure SATA As and Fourth.IDE.Master/Slave items appear only when
you set the ATA/IDE Configuration to [Enhanced] mode.
Configure SATA As [IDE]
Sets the configuration for the Serial ATA connectors supported by the
Southbridge chip.
If you want to use the Serial ATA hard disk drives as Parallel ATA physical
storage devices, set this item to [IDE].
Set this item to [RAID] if you want to create a RAID volume from Serial ATA
hard disk drives.
Place a jumper cap on pins 1-2 of the
RAID_SEL1 jumper to use the LSI Logic
Embedded SATA RAID Utility (for RAID 0 or RAID 1 configuration; supported
on Windows ® 2000/2003 Server/XP and Red Hat ® Enterprise ver. 3.0). Refer
to section 4.2.Jumpers for details.
Place a jumper cap on pins 2-3 of the RAID_SEL1 jumper to use the Intel ®
Matrix Storage Manager (for RAID 0 or RAID 1 configuration; supported on
Windows ® 2000/2003 Server/XP).
5.3.4. IDE Configuration
The items in this menu allow you to set or change the configurations for the IDE
devices installed in the system. Select an item then press if you want to
configure the item.
IDE Configuration
ATA/IDE Configuration [Enhanced]
Configure SATA As [IDE]
Primary IDE Master : [Not Detected]
Primary IDE Slave : [Not Detected]
Tertiary IDE Master : [Not Detected]
Tertiary IDE Slave : [Not Detected]
Fourth IDE Master : [Not Detected]
Fourth IDE Slave : [Not Detected]
IDE Detect Time Out (Sec) [35]
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
BIOS SETUP UTILITY
Main
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Options
Disabled
Compatible
Enhanced
