6-34 Chapter 6: RAID Configuration
6.3.2. Creating.a.RAID.1.set.(Mirror)
To create a RAID 1 set:
1. From the utility main menu, select 1..Create.RAID.Volume, then press
. This screen appears.
Intel(R) Matrix Storage Manager Option ROM v5.1.0.1022 ICH7R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can
be used to uniquely identify the RAID volume. This name is case
sensitive and cannot contain special characters.
Name:
RAID Level:
Disks:
Strip Size:
Capacity: Volume1
RAID1(Mirror)
Select Disks
N/A
0.0 GB
Create Volume
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
2. Enter a name for the RAID 1 set, then press .
3. Highlight RAID.Level, press the up/down arrow key to select RAID.1.
(Mirror), then press .
4. Follow steps 4 to 5 and 7 to 9 of the previous section to create the RAID 1
set.
