Asus RS120-E4/PA4 User Manual
Page 63
ASUS RS120-E4/PA4
4-15
11.. Backplane.SMBus.connector.(6-1.pin.BPSMB1)
This connector allows you to connect SMBus (System Management Bus)
devices. Devices communicate with an SMBus host and/or other SMBus
devices using the SMBus interface.
P5M2-R
®
P5M2-R.SMBus.connector
BPSMB1
1
I2C_6_CLK#
GND
I2C_6_DATA#
+5V
HWM_FANOUT
