6-36 Chapter 6: RAID Configuration
6.3.4. Creating.a.RAID.5.set.(Parity)
To create a RAID 5 set:
1. From the utility main menu, select 1..Create.RAID.Volume, then press
. This screen appears.
Intel(R) Matrix Storage Manager Option ROM v5.1.0.1022 ICH7R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive
and cannot contain special characters.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID5(Parity)
Select Disks
128KB
0.0 GB
Create Volume
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
2. Enter a name for the RAID 10 set, then press .
3. Highlight RAID.Level, press the up/down arrow key to select RAID.5.
(Parity), then press .
4. Follow steps 4 to 9 of section 6.3.1.Creating.a.RAID.0.set.(striped) to create
the RAID 5 set.
