ASUS RS120-E4/PA4 5-27
5.4.6 Peripheral Devices Configuration
Onboard.Floppy.Controller.[Enabled]
Allows you to enable the onboard floppy disk drive controller.
Configuration options: [Disabled] [Enabled]
Serial.Port1.Address.[3F8/IRQ4]
Allows you to select the Serial Port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3]
Serial.Port2.Address.[2F8/IRQ3]
Allows you to select the Serial Port2 base address.
Configuration options: [Disabled] [2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows you to select the Serial Port2 mode.
Configuration options: [Normal] [IrDA] [ASK IR]
Parallel.Port.Address.[378]
Allows you to select the Parallel Port base addresses.
Configuration options: [Disabled] [378] [278] [3BC]
Parallel.Port.Mode.[Normal]
Allows you to select the Parallel Port mode.
Configuration options: [Normal] [Bi-directional] [ECP] [EPP] [ECP and EPP]
Parallel Port IRQ [IRQ7]
Allows you to specify the Parallel Port IRQ.
Configuration options: [IRQ5] [IRQ7]
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Allows BIOS to Enable
or Disable Floppy
Controller
Configure W83627EHG-A Super IO Chipset
Onboard Floppy Controller [Enabled]
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
