6.3 Intel ® Matrix Storage Manager Option
ROM Utility
The Intel ® Matrix Storage Manager Option ROM utility allows you to create RAID 0,
RAID 1,RAID 10, and RAID 5 set(s) from Serial ATA hard disk drives.
To enter the Intel
® Matrix Storage Manager Option ROM Utility:
1. Turn on the system after installing all Serial ATA hard disk drives.
2. During POST, press to display the utility main menu.
The navigation keys at the bottom of the screen allow you to move through
the menus and select the menu options.
The RAID BIOS setup screens shown in this section are for reference only and
may not exactly match the items on your screen.
Intel(R) Matrix Storage Manager Option ROM v5.1.0.1022 ICH7R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes:
None defined.
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
1 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
2 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
3 XXXXXXXXXXX XXXXXXXX XX.XXGB Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
