iBypass HD
Plan the Installation
Before you begin the installation of your the iBypass HD device, determine the following information:
• IP address of the iBypass HD device for the management interface; or a range of IP addresses if you are
deploying multiple the iBypass HD devices
• Net Mask for the iBypass HD
• IP address of the remote management console, if deployed over a WAN; this address will be used for SNMP
traps (when available)
• Gateway to the remote management console, if deployed over a WAN
• Port assignments for the network and monitor port connections
Make sure you have a suitable location to install the iBypass HD device. For power redundancy, use two independent
power sources.
Unpack and Inspect the iBypass HD device
Carefully unpack the iBypass HD device, power supplies, and all cables that are provided. The iBypass HD is delivered
with the following:
• (1) the iBypass HD chassis
• (1 to 4) DBMs (might already be installed in the iBypass HD chassis)
• (2) Power cords (AC model only)
• (1) Cable, 3 Meter, RJ45, CAT 5e 4-Pair (Purple)
• (1) DB9-to-RJ45 RS232 adapter for use with the CLI
• (1) iBypass HD Quick Install Guide (one sheet)
• (1) CD containing the iBypass HD User Guide (this document)
• Service Plan Reference Guide
• Registration instruction card
• Extended Warranty if purchased
Check the packing slip against parts received. If any component is missing or damaged, contact Net Optics Customer
Service immediately at +1 (408) 737-7777. (Note: SFP modules are ordered and shipped separately.)
