Chapter 2 installing the ibypass hd – Net Optics iBypass HD User Manual
Page 13
9
iBypass HD
Chapter 2
Installing the iBypass HD
This chapter describes how to install and connect iBypass HD devices. The procedure for installing the iBypass HD
follows these basic steps:
1. Plan the installation
2. Unpack and inspect the iBypass HD device
3. Install DBM modules
4. Install SFP modules
5. Rack mount the iBypass HD device
6. Connect power to the iBypass HD
7. Connect the command line interface (CLI) RS232 RJ45 port or the Management port (SSH)
8. Log into the CLI
9. Use the CLI Help command
10. Configure the iBypass HD parameters using the CLI
11. Connect the iBypass HD to the network
12. Connect IPSs to the iBypass HD
13. Configure the bypass switches
14. Check the installation
