Data Sheet
JRCW016A0R Orca Series; DC-DC Converter Power Modules
36–75 Vdc Input; 28.0Vdc Output; 16Adc Output
November 20, 2013
©2012 General Electric Company. All rights reserved.
Page 3
Electrical Specifications
(continued)
Parameter
Device
Symbol
Min
Typ
Max
Unit
Output Voltage Set-point
(V
IN
=V
IN,nom
, I
O
=I
O, max
, T
c
=25°C)
All
V
O, set
27.5 28 28.5 V
dc
Output Voltage Set-Point Total Tolerance
(Over all operating input voltage, resistive load, and temperature
conditions until end of life)
All V
O
27.0
29.0
V
dc
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All
0.1 0.2 %V
o,set
Load (I
O
=I
O, min
to I
O, max
) All
0.1 0.2 %V
o,set
Temperature (T
c
= -40ºC to +100ºC)
All
0.25 0.5 %V
o,set
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
)
RMS (5Hz to 20MHz bandwidth)
All
45 55 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth)
All
80
200
mV
pk-pk
External Capacitance
(ESR
> 2.5 mΩ)
1
All,
except -T
C
O
440 6500
μF
Without the Tunable Loop
(ESR
MAX
= 80mΩ)
1
-T
C
O,
440 470
μF
With the Tunable Loop
(ESR > 50 mΩ)
2
-T C
O
440
10,000
μF
Output Power (V
o
=28V to 35.2V)
All
P
O,max
450 W
Output Current
All
I
o
0
16.0
A
dc
Output Current Limit Inception (Constant current until V
o
<
V
trimMIN
,
duration <4s)
All
I
O, lim
17.0
21.0 A
dc
Output Short Circuit Current (V
O
≤ 0.25V
dc
) All
I
O, sc
30
A
rms
Efficiency
V
IN
=V
IN, nom
, T
c
=25°C I
O
=I
O, max ,
V
O
= V
O,set
All
η 93.0
93.5
%
Switching Frequency
f
sw
175
kHz
Dynamic Load Response
(Io/t=1A/10s; V
in
=V
in
,nom; T
c
=25°C; Tested with a 470 μF
aluminum and a 10 µF ceramic capacitor across the load.)
Load Change from Io= 50% to 75% of Io,max:
Peak Deviation
Settling Time (Vo<10% peak deviation)
All
V
pk
t
s
2
1.5
3
%V
O, set
ms
Load Change from Io= 25% to 50% of Io,max:
Peak Deviation
Settling Time (Vo<10% peak deviation)
V
pk
t
s
2
1.5
3
%V
O, set
ms
1
Note: use a minimum 2 x 220uF output capacitor. Recommended capacitor is Nichicon CD series, 220uF/35V. If the ambient temperature is less
than -20
O
C, use more than 3 of recommended minimum capacitors.
2
External capacitors may require using the new Tunable Loop feature to ensure that the m
odule is stable as well as getting the best transient
response. See the Tunable Loop section for details.
Isolation Specifications
Parameter
Symbol
Min
Typ
Max
Unit
Isolation Capacitance
C
iso
15
nF
