4–22
EPM 4500 SUB METER – INSTRUCTION MANUAL
MODBUS MEMORY MAP
CHAPTER 4: COMMUNICATIONS
0422*
1058
Meter #4 Phase-to-Phase Voltage A
R
V
Meter #4 Instantaneous Voltage
0424*
1060
Meter #4 THD Phase B
R
%
Meter #4 Total Harmonic Distortion
0426*
1062
Meter #4 Phase Angle B
R
degrees
Meter #4 Phase Angle
0428*
1064
Meter #4 Phase-to-Phase Voltage B
R
V
Meter #4 Instantaneous Voltage
042A*
1066
Meter #4 THD Phase C
R
%
Meter #4 Total Harmonic Distortion
042C*
1068
Meter #4 Phase Angle C
R
degrees
Meter #4 Phase Angle
042E*
1070
Meter #4 Phase-to-Phase Voltage C
R
V
Meter #4 Instantaneous Voltage
0430*
1072
Meter #5 THD Phase A
R
%
Meter #5 Total Harmonic Distortion
0432*
1074
Meter #5 Phase Angle A
R
degrees
Meter #5 Phase Angle
0434*
1076
Meter #5 Phase-to-Phase Voltage A
R
V
Meter #5 Instantaneous Voltage
0436*
1078
Meter #5 THD Phase B
R
%
Meter #5 Total Harmonic Distortion
0438*
1080
Meter #5 Phase Angle B
R
degrees
Meter #5 Phase Angle
043A*
1082
Meter #5 Phase-to-Phase Voltage B
R
V
Meter #5 Instantaneous Voltage
043C*
1084
Meter #5 THD Phase C
R
%
Meter #5 Total Harmonic Distortion
043E*
1086
Meter #5 Phase Angle C
R
degrees
Meter #5 Phase Angle
0440*
1088
Meter #5 Phase-to-Phase Voltage C
R
V
Meter #5 Instantaneous Voltage
0442*
1090
Meter #6 THD Phase A
R
%
Meter #6 Total Harmonic Distortion
0444*
1092
Meter #6 Phase Angle A
R
degrees
Meter #6 Phase Angle
0446*
1094
Meter #6 Phase-to-Phase Voltage A
R
V
Meter #6 Instantaneous Voltage
0448
1096
Meter #6 THD Phase B
R
%
Meter #6 Total Harmonic Distortion
044A*
1098
Meter #6 Phase Angle B
R
degrees
Meter #6 Phase Angle
044C*
1100
Meter #6 Phase-to-Phase Voltage B
R
V
Meter #6 Instantaneous Voltage
044E*
1102
Meter #6 THD Phase C
R
%
Meter #6 Total Harmonic Distortion
0450*
1104
Meter #6 Phase Angle C
R
degrees
Meter #6 Phase Angle
0452*
1106
Meter #6 Phase-to-Phase Voltage C
R
V
Meter #6 Instantaneous Voltage
0454*
1108
Meter #7 THD Phase A
R
%
Meter #7 Total Harmonic Distortion
0456*
1110
Meter #7 Phase Angle A
R
degrees
Meter #7 Phase Angle
0458*
1112
Meter #7 Phase-to-Phase Voltage A
R
V
Meter #7 Instantaneous Voltage
045A*
1114
Meter #7 THD Phase B
R
%
Meter #7 Total Harmonic Distortion
045C*
1116
Meter #7 Phase Angle B
R
degrees
Meter #7 Phase Angle
045E*
1118
Meter #7 Phase-to-Phase Voltage B
R
V
Meter #7 Instantaneous Voltage
0460*
1120
Meter #7 THD Phase C
R
%
Meter #7 Total Harmonic Distortion
0462*
1122
Meter #7 Phase Angle C
R
degrees
Meter #7 Phase Angle
0464*
1124
Meter #7 Phase-to-Phase Voltage C
R
V
Meter #7 Instantaneous Voltage
0466*
1126
Meter #8 THD Phase A
R
%
Meter #8 Total Harmonic Distortion
Table 4–1: Modbus Memory Map (Sheet 14 of 15)
Hex
Addr
Addr
Description
R/W
Units
Notes
