CHAPTER 2: INSTALLATION WIRING
EPM 4500 SUB METER – INSTRUCTION MANUAL 2–13
Note In the above table:
• L#1(+) indicates that Line 1 points towards the ‘dot’ or H1 of the CT
• L#2(–) indicates that Line 2 points away from the ‘dot’ or H1 of the CT
Table 2–5: Line Association Table for 1-Phase 3-Wire Wiring
Meter MCI
Board CT
Reference Voltage
Line
Meter MCI
Board CT
Reference Voltage
Line
1 1 L#1(+) and L#2(–) 13 13 L#1(+) and L#2(–)
2 2 L#1(+) and L#2(–) 14 14 L#1(+) and L#2(–)
3 3 L#1(+) and L#2(–) 15 15 L#1(+) and L#2(–)
4 4 L#1(+) and L#2(–) 16 16 L#1(+) and L#2(–)
5 5 L#1(+) and L#2(–) 17 17 L#1(+) and L#2(–)
6 6 L#1(+) and L#2(–) 18 18 L#1(+) and L#2(–)
7 7 L#1(+) and L#2(–) 19 19 L#1(+) and L#2(–)
8 8 L#1(+) and L#2(–) 20 20 L#1(+) and L#2(–)
9 9 L#1(+) and L#2(–) 21 21 L#1(+) and L#2(–)
10 10 L#1(+) and L#2(–) 22 22 L#1(+) and L#2(–)
11 11 L#1(+) and L#2(–) 23 23 L#1(+) and L#2(–)
12 12 L#1(+) and L#2(–) 24 24 L#1(+) and L#2(–)
