HW/HC004/005/006 Series DC-DC Power Module:
18-36Vdc & 36-75Vdc Input; 1.0V-5Vdc Output; 4A - 6A Output Current
LINEAGE
POWER
5
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter
Device
Symbol
Min
Typ
Max
Unit
Remote On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
; open collector or equivalent,
Signal referenced to V
IN-
terminal)
Negative Logic: device code suffix “1”
Logic Low = module On, Logic High = module Off
Positive Logic: No device code suffix required
Logic Low = module Off, Logic High = module On
Logic Low Specification
Remote On/Off Current – Logic Low
All
I
on/off
0.15
1.0
mA
On/Off Voltage:
Logic Low
All
V
on/off
0.0
1.2
V
Logic High – (Typ = Open Collector)
All
V
on/off
5.8
15
V
Logic High maximum allowable leakage current
All
I
on/off
10
μA
Turn-On Delay and Rise Times
(I
O
=I
O, max
)
T
delay
= Time until V
O
= 10% of V
O,set
from either
application of Vin with Remote On/Off set to On or
operation of Remote On/Off from Off to On with Vin
already applied for at least one second.
5V, 3.3V
T
delay
100
ms
T
rise
40
ms
2.5V, 2.0V,
1.8V, 1.5V,
1.2V, 1.0V
T
delay
12
ms
T
rise
= time for V
O
to rise from 10% of V
O,set
to 90%
of V
O,set
.
T
rise
3
ms
5V
V
O, limit
7.0
V
Output Overvoltage Protection
#
3.3V
4.6
V
2.5V
3.5
V
Values are the same for HW and HC codes
2.0V
3.2
V
1.8V
2.8
V
1.5V
2.5
V
1.2V
2.0
V
1.0V
1.8
V
Overtemperature Protection
All
T
ref
125
°C
(See Feature Descriptions)
Input Undervoltage Lockout
Turn-on Threshold
All HW
33
36
V
Turn-off Threshold
All HW
27
30
V
Turn-on Threshold
All HC
17
18
V
Turn-off Threshold
All HC
13.5
15
V
# More accurate Overvoltage protection can be accomplished externally by means of the remote On/Off pin.
