Data Sheet
October 4, 2013
HW/HC004/005/006 Series DC-DC Power Module:
18-36Vdc & 36-75Vdc Input; 1.0V-5Vdc Output; 4A - 6A Output Current
LINEAGE POWER 3
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Output Voltage Set-point
5V, 3.3V
2.5V, 2.0V,
1.8V, 1.5V
V
O, set
-1.0  +1.0 % V
O, nom
(V
IN
=V
IN,nom
, I
O
=I
O, max
, T
ref
=25°C) 1.2V, 1.0V V
O, set
-1.25  +1.25 % V
O, nom
Output Voltage All V
O
-3.0

+3.0 % V
O, nom
(Over all operating input voltage, resistive load,
and temperature conditions until end of life)
Adjustment Range All V
O
-10.0 +10.0 % V
O, nom
Selected by external resistor
Output Regulation
Line (V
IN
=V
IN, min
to V
IN, max
) All   10 mV
Load (I
O
=I
O, min
to I
O, max
) All   15 mV
Temperature (T
ref
=T
A, min
to T
A, max
) All   1.00 %
Output Ripple and Noise on nominal output
(V
IN
=V
IN, nom
and I
O
=I
O, min
to I
O, max
)
RMS (5Hz to 20MHz bandwidth) All  8 15 mV
rms
Peak-to-Peak (5Hz to 20MHz bandwidth) All  25 50 mV
pk-pk
External Capacitance All C
O, max
  470 μF
Output Current 5V I
o
0 4.0 Adc
3.3V I
o
0 5.0 Adc
2.5V, 2.0,
1.8V, 1.5V,
1.2V, 1.0V
I
o
0 6.0 Adc
Output Current Limit Inception 5V I
O, lim
 6.5  Adc
( Hiccup Mode ) 3.3V I
O, lim

7

Adc
2.5V, 2.0V,
1.8V, 1.5V,
1.2V, 1.0V
I
O, lim
 8.5  Adc
Output Short-Circuit Current 5V I
O, s/c
 2.4  A rms
(V
O
≤250mV) ( Hiccup Mode )
3.3V I
O, s/c
 2.4  A rms
2.5V, 2.0V,
1.8V, 1.5V,
1.2V, 1.0V
I
O, s/c
 2.8  A rms
