Data Sheet
October 7, 2013
KW010/015/020/025 Series Power Modules:
36
– 75Vdc Input; 1.2 to 5.0Vdc Output; 10 to 25A Output current
LINEAGE POWER 4
Electrical Specifications (continued)
Parameter Device Symbol Min Typ Max Unit
Efficiency A η 92.0 %
V
IN
= V
IN, nom
, T
A
=25°C F η 91.0 %
I
O
=I
O, max ,
V
O
= V
O,set
G η 89.0 %
Y η 87.0 %
M η 85.0 %
P η 84.0 %
Switching Frequency All f
sw
190 200 235 kHz
Dynamic Load Response
(dIo/dt=0.1A/

s; V
IN
= V
IN, nom
; T
A
=25°C)
Load Change from Io= 50% to 75% or 25% to
50% of Io,max;
Peak Deviation All V
pk
 2  % V
O, set
Settling Time (Vo<10% peak deviation) All t
s
 200   s
(dIo/dt=1A/

s; V
IN
= V
IN, nom
; T
A
=25°C)
Load Change from Io= 50% to 75% or 25% to
50% of Io,max;
Peak Deviation All V
pk
 5  % V
O, set
Settling Time (Vo<10% peak deviation) All t
s
 200  
s
Isolation Specifications
Parameter Device Symbol Min Typ Max Unit
Isolation Capacitance All C
iso
 1000  pF
Isolation Resistance All R
iso
10
  MΩ
I/O Isolation Voltage All All   1500 V
dc
General Specifications
Parameter Device Min Typ Max Unit
Calculated Reliability Based upon Telcordia SR-332
Issue 2: Method
I, Case 3, (I
O
=80%I
O, max
, T
A
=40°C,
Airflow = 200 lfm), 90% confidence
MTBF F 2,864,101 Hours
FIT F 349 10 9 /Hours
Powered Random Vibration (V
IN
=V
IN, min
, I
O
=I
O, max
, T
A
=25°C, 0 to
5000Hz, 10Grms)
All 90 Minutes
Weight All

11.3 (0.4)

g (oz.)
